| Axles |
[72BS] (2) 7,000# Electric / Spring
Available Options
[82BS] (2) 8,000# Oil Bath w/14 Ply LR-G Tires Electric / Spring[92BS] (2) 7,000# w/14 Ply LR-G Tires Electric / Spring[B2BS] (2) 8,000# Oil Bath Axles, 235/80 LR-E Tires Electric / Spring
|
| Suspension |
6-Leaf Slipper Spring Suspension |
| Tongue |
6″ Channel Tongue |
| Coupler |
[J] BP 2-5/16″ Adjustable (14,000 lb.)
Available Options
[J] BP 2-5/16″ Adjustable (14,000 lb.)[P] 3″ Pintle Eye – Channel-Mount (20,000 lb.)[R] GN 2-5/16″ Round (25,000 lb.) w/ Toolbox[S] GN 2-5/16″ Square (25,000 lb.) w/ Toolbox[T] BP 2-5/16″ Adjustable Coupler (20,000 lb.) w/HD 6-Hole Channel Bracket
|
| Safety Chains |
5/16″ Grade 70 Safety Chain w/Clevis hook (2 each) |
| Jack |
Drop Leg Jack (10,000lb)
Available Options
[-JA02] 2-Speed Gooseneck Jack Upgrade (12,000 lb.)[-JA05] 1 Hydraulic Jack (BP Only)[-JA06] 2 Hydraulic Jacks (GN Upgrade)[-JA13] Rear Trailer Support Jacks[-JA17] Single 2-speed Jack (12,000 lb.) (BP Only)[-JA19] 2 Hydraulic Jacks for BP[-JA21] Dual Jacks for BP
|
| Frame |
6″ Channel Frame
Available Options
[-CM12] 12″ OC Crossmembers
|
| Cross-Members |
3” Channel Crossmembers 16” oc |
| Bump Rail |
Front Bump Rail |
| Floor |
2″ Treated Pine Lumber Deck
Available Options
[-BWFT] Blackwood Pro Full Deck (Tail Only)[-SF03] 11ga DP Steel Floor on Dovetail[-BWOD] Blackwood Pro Outer Deck[-BWFD] Blackwood Pro Full Deck[-FLRO] Rough Oak Floor[-FLNF] No Flooring[-SF01] 11ga (1/8″) DP Steel Floor w/ Flushmount D-Rings & 12″ OC[-SF04] 3/16″ DP Steel Floor w/ Flushmount D-Rings & 12″ OC
|
| Fenders |
9″ x 72″ Treadplate Aluminum Fenders
Available Options
[-FE01] 1/4″ DP HD Weld on Fenders Tandem Axle[-FE02] 1/4″ DP HD Weld on Fenders Triple Axle[-FE04] Weld on Fenders
|
| Ramps |
5′ Slide-In Ramps w/ Holders
Available Options
[-NRNP] No Ramps No Ramp Pockets
|
| Stake Pockets |
24″ Stake Pocket Spacing
Available Options
[-2SPF] 2 Stake Pockets In Front of Trailer[-NSP1] No Stake Pockets
|
| Lights |
Available Options
[-LT10] GN Light Bar w/ 4 Lights (GN Only)
|
| Wiring |
All-Weather Wiring Harness (7-way RV) |
| Tires |
ST235/80R16 Radial Tires 10 ply (3,520 lbs.) |
| Paint Color |
[K] Primer + Black Powder Coat
Available Options
View Color Options
[1] Primer + Red Powder Coat[3] Primer + White Powder Coat[5] Primer + Tractor Orange Powder Coat[6] Primer + Grey Powder Coat[8] Primer + Desert Tan Powder Coat[B] Primer + Jet Blue Coat (NEW!)[J] Primer + Industrial Green Coat (NEW!)[Y] Primer + Industrial Yellow Coat (NEW!)[G] Primer + Slime Green Coat (NEW!)
|
| Tie-Downs |
(6) Flushmount D-rings
Available Options
[-RT01] 1 Pair Weld-On Ratchets[-DR01] 1 Extra Pair D-Rings[-NDR1] No D-Rings[-DR21] 1 Extra Pair Flushmount D-Rings[-SRRR] 2″ Rubrail
|
| Breakaway System |
Electric Breakaway System w/ Charger |
| Battery |
Available Options
[-BYBC] 1 Extra Battery Charger 12V[-BYSL] Solar Battery Charger
|
| Storage |
Available Options
[-GNC2] 2 GN Lockable Chain Holders[-GNCH] GN Lockable Chain Holder[-TB02] Top Riser Toolbox[-TB03] Full Size Divided Toolbox Upgrade[-TB05] Front Toolbox[-TB06] Locking Lid Over Tongue
|
| Cargo Winch |
Available Options
[-WN01] Plate for Winch (BP Only)[-WN02] HD GN Winch Plate[-WN03] Winch Plate w/ Welded Receiver Hitch[-WN04] Gooseneck Winch Plate[-WN12] Winch 12.5K w/Plate & Battery[-WN18] Winch 18K w/HD Plate & Battery[-WN95] Winch 10k w/ Plate & Battery[-WNRR] Roller on Rear of Deck for Winch Cable
|
| Tail |
[S] Straight Deck w/ Rear Slide-in Ramps
Available Options
[5] 3.5′ Dovetail w/2 Monster Ramps[B] 2′ Dovetail w/ 5′ Fold-up Ramps[C] Straight deck w/ 5′ Fold-up Ramps[D] 2′ Dovetail w/ 31 x 66 HD Fold-up Ramps[K] 2′ Dovetail w/ Split Heavy Duty Gate[N] 2′ Dovetail w/ 5′ Rear Slide-in Ramps[L] Straight deck w/ 31 x 66 HD Fold-up Ramps
|
| Other Options |
Available Options
[-FR01] Fork Rack[-GV09] 9,900 G.V.W.R.[-GV16] 16,000 GVWR Must have 16k coupler/7k axles min.[-RATL] Ramp Gate Transition Lip
|
