Description
The TYM T254 HST is the perfect tractor for all the small chores that have to be done. With available loader, mower, and backhoe, the T254 gives you access to the tools you need for the things you love to do.
w/loader
$18,399.00
**Prices are subject to change without warning. For the most up to date pricing contact the store. Final price reflected at check out.
The TYM T254 HST is the perfect tractor for all the small chores that have to be done. With available loader, mower, and backhoe, the T254 gives you access to the tools you need for the things you love to do.
w/loader
| Model | T254H |
|---|
Key Specifications
Specifications
|
ENGINE
|
|
|---|---|
| Engine manufacturer | Yanmar 3TNV80F |
| Type | Natural Aspiration |
| Gross engine power | 23.9 hp | 17.8 kW |
| PTO power | 18.8 hp | 14.0 kW |
| Rated engine speed | 3000 rpm |
| No. of cylinders | 3 |
| Displacement | 77.3 cu. in. |
| Air cleaner | Single Dry |
| Alternator | 12V, 40A |
| Fuel system | IDI |
|
POWERTRAIN
|
|
| Transmission type | HST |
| No. of speeds | Infinite 2-range |
| Max. traveling speed | 11.0 mph |
| Brakes | Wet Disc |
| Steering | Hydrostatic |
| Clutch | Dry Single Plate |
|
HYDRAULIC SYSTEM
|
|
| Pump type | Single Gear Pump |
| Implement flow | 4.18 gpm |
| Steering flow | 2.77 gpm |
| Total flow | 6.95 gpm |
| Category, 3-point hitch | I (N) |
| Hitch lift capacity | 1214 lb |
| Hitch lift capacity at 24 inches behind link ends | 1101 lb |
| Lift control type | Position |
| No. of standard remote valves | Optional (1) |
|
PTO
|
|
| PTO type | Transmission PTO w/ ORC/Independent |
| PTO control | Electric/Hydro |
| PTO rear | 540 rpm |
|
CAPACITIES
|
|
| Fuel tank | 5.81 gal |
| Coolant | 3.8 qt |
| Crankcase | 2.9 qt |
| Transmission/Hydraulics system | 3.7 gal |
| Front axle | 3.7 qt |
|
DIMENSIONS & WEIGHTS
|
|
| Overall length with 3-point hitch | 100.5 in. |
| Overall width | 45.8 in. |
| Wheelbase | 57.5 in. |
| Height to top of ROPS | 91.3 in. |
| Min. ground clearance | 9.4 in. |
| Min. turn radius with brakes | 88.58 in. |
| Min. turn radius without brakes | 100 in. |
| Weight with ROPS | 1638 lb |
|
STANDARD TIRES
|
|
| R3 Turf – Front | Turf Master 20×8.00-10 NHS TL 4PR |
| R3 Turf – Rear | Multi-Trac CS 29×12.50-15 NHS TL 4PR |
| R4 Industrial – Front | Trac Chief 20×8.00-10 NHS TL 4PR |
| R4 Industrial – Rear | Trac Chief 27×12.5-15 NHS TL 4PR |
| R4 Large Industrial – Front | Trac Chief 23×8.50-12 NHS TL 4PR |
| R4 Large Industrial – Rear | Trac Chief 12-16.5 NHS TL 6PR |
More information on T254 HST (March, 2023)
Images may show optional equipment.
